Multi-Functional CNC miliing machine Drill Tap Machine TV700
Product Description:
The Precision and Accurate Drilling CNC Drill Tap Machine Tv600 is a high-quality and efficient machine designed for precision drilling and tapping operations. It is equipped with advanced features and offers reliable performance for various industrial applications. This machine is manufactured by LiSN, a reputable brand from China, and it comes with SGS certification, ensuring its quality and compliance with industry standards.
Technical Parameters:
| Item | Specifications | MODELS→ | TV500 | TV600 |
| Travel Range | X/Y/Z Axis Travel | mm | 500/400/300 | 600/400/300 |
| Distance From Spindle Nose To worktable | mm | 130-450 | 150-450 |
| Distance from spindle center to column track | mm | 410 | 410 |
Worktable | Worktable(WidthXLength) | mm | 650 X400 | 720 X400 |
| Max Load Bearing Of Worktable | kg | 200 | 200 |
| T-Slot | mm | 3 x 14 x 125 | 3 x 14 x 125 |
Spindle | Spindle Hole Taper | type | BT30 | BT30 |
| Spindle Speed Range | rpm | 20000 | 20000 |
| Motor | Spindle Motor Power | kw | 5.5 | 5.5 |
| Accuracy | X/Y/Z Position Accuracy | mm | ±0.005/300 | ±0.005/300 |
| Machine Dimension | Machine Weight | kg | 3000 | 3000 |
Applications:
The Precision and Accurate Drilling CNC Drill Tap Machine Tv600 is suitable for various applications in industries such as manufacturing, automotive, aerospace, and more. It is ideal for drilling and tapping operations on materials like metal, plastic, and wood. Its precise and reliable performance makes it a valuable asset for producing high-quality components and parts.
Detail drawing:
FAQ:
1. Is it all right to make customer's own brand name?
A: yes. we are available with OEM
2. Are you a manufactuer or trading company?
A:We are the manufacturer
3. Can you do the design for us?
A: yes. if you want a different control system design or higher column , we are available.
4 . What is your terms of delivery?
A: FOB shenzhen.
5. What's your payment term?
A: T/T OR L/C at sight
